316 stainless steel is a molybdenum-bearing austenitic stainless steel, offering enhanced corrosion resistance compared to 304, especially in chloride and acidic environments. Due to its superior pitting and crevice corrosion resistance, excellent mechanical properties, high-temperature strength, and good weldability, it is widely used in marine, chemical, pharmaceutical, and food processing industries. You can find equivalent grades in various international standards, such as X5CrNiMo17-12-2/1.4401 (Europe EN 10088-3), 06Cr17Ni12Mo2/0Cr17Ni12Mo2 (China GB/T 1220), SUS316 (Japan JIS G4303), and 03X17H14M3 (Russia GOST 5632-76).
1: Steel equivalent
Country | USA | EN | China | Japan | Russia |
Standard | ASTM A276/276M | EN10088-3 | GB/T1220 | JIS G4303 | GOST 5632-76 |
Grade | 316 | X5CrNiMo17-12-2/1.4401 | 06Cr17Ni12Mo2 | SUS316 | 03X17H14M3 |
2: Chemical composition
Grade | C | Si | Mn | P | S | Cr | Ni | N |
316 | 0.08Max | 1.0Max | 2.0Max | 0.045Max | 0.03Max | 16-18 | 10-14 | / |
X5CrNiMo17-12-2/1.4401 | 0.07Max | 1.0Max | 2.0Max | 0.045Max | 0.03Max | 16.5-18.5 | 10-13 | 0.11Max |
06Cr17Ni12Mo2 | 0.08Max | 1.0Max | 2.0Max | 0.045Max | 0.03Max | 16-18 | 10-14 | / |
SUS316 | 0.08Max | 1.0Max | 2.0Max | 0.045Max | 0.03Max | 16-18 | 10-14 | / |
03X17H14M3 | 0.03Max | 0.4Max | 1.0-2.0 | 0.030Max | 0.02Max | 16.8-18.3 | 13.5-15 | / |
3: Mechanical properties
Mechanical properties for 06Cr17Ni12Mo2/0Cr17Ni12Mo2 from standard GB/T1220 and SUS316 from JIS G4303.
Grade | Tensile strength | Yield strength | Alongation | Area of reduction | Hardness |
06Cr17Ni12Mo2 | 520Mpa Min | 205Mpa Min | 40% Min | 60% Min | HBW187Max |
SUS316 | 520Mpa Min | 205Mpa Min | 40% Min | 60% Min | HBW187Max |
Mechanical properties for X5CrNiMo17-12-2/1.4401 from standard EN10088-3.
Steel grade | Size range | Tensile strength | Yield strength | Alongation | Impact value at RT/J | Hardness /HBW | ||
L | Tr | L | Tr | |||||
X5CrNiMo17-12-2/1.4401 | d≤160 | 500-700Mpa | 200Mpa Min | 40% Min | / | 100J Min | / | 215Max |
160＜d≤250 | 500-700Mpa | 200Mpa Min | / | 30% Min | / | 60J Min | 215Max | |
Mechanical properties at room temperature of steels in the COLD-WORKED condition from standard EN10088-3
Steel grade | Tensile strength level | 0.2% proof strength | Tensile strength/Rm | Elongation |
X5CrNiMo17-12-2 /1.4401 | C700 | 350Mpa Min | 700-850Mpa | 20% Min |
C800 | 500Mpa Min | 800-1000Mpa | 12% Min |
Minimum values for the 0.2% and 1% proof strength of austenitic steels at elevated temperatures according to standard EN10088-3
Steel garde | HT condition | Minimum 0.2% proof strength at a temperature of: | |||||||||
100℃ | 150℃ | 200℃ | 250℃ | 300℃ | 350℃ | 400℃ | 450℃ | 500℃ | 550℃ | ||
X5CrNiMo17-12-2 /1.4401 | AT | Mpa or N/mm2 | |||||||||
175 | 158 | 145 | 135 | 127 | 120 | 115 | 112 | 110 | 108 | ||
Minimum 1% proof strength at a temperature of: | |||||||||||
100℃ | 150℃ | 200℃ | 250℃ | 300℃ | 350℃ | 400℃ | 450℃ | 500℃ | 550℃ | ||
Mpa or N/mm2 | |||||||||||
210 | 190 | 175 | 165 | 155 | 150 | 145 | 141 | 139 | 137 | ||
AT = Solution annealed
4: Supply size & Tolerance & Stock size
Product type | Size range | Length |
Hot rolled bar | Φ10-Φ130mm | 5000-7000mm |
Hot forged bar | Φ140-Φ600mm | 2000-5800mm |
Hot rolled plate/sheet | T:2-60mm; W:310-810mm | 6000-12000mm |
Hot forged plate | T:70-250mm; W:310-810mm | 2000-5800mm |
Hot Forged block | T: 260-500mm; W: 300-1000mm | 2000-5800mm |
Surface Finish | Turned | Milled | Grinding(Best) | Polished(Best) | Peeled(Best) | Black Forged | Black Rolled |
Tolerance | +0/+3mm | +0/+3mm | +0/+0.05mm | +0/+0.05mm | +0/+0.1mm | +0/+5mm | +0/+1mm |
Straighness | 1mm/1000mm max. | 3mm/1000mm max. | |||||
Qilu steel stock hot rolled bar and forged bars more than ten thousands tons every month, below our our stock size.
1): Stock diameter for hot rolled bar
10 | 12 | 15 | 18 | 20 | 22 | 25 | 28 | 30 | 32 | 35 | 38 | 40 | 45 | 50 |
55 | 60 | 65 | 70 | 75 | 80 | 85 | 90 | 95 | 100 | 105 | 110 | 120 | 130 | 140 |
150 | 160 | 170 | 180 | 190 |
2) : Stock diameter for hot forged bar
| 200 | 210 | 220 | 230 | 240 | 250 | 260 | 270 | 280 | 290 |
300 | 310 | 320 | 330 | 340 | 350 | 360 | 370 | 380 | 390 |
400 |
Since the stocks change everyday, if you want to know our stock available information, please contact our salesman.
5: Ultrasonic Test
EN10228-3 class III or Sep 1921-84 D/D
6：Steel making & Forging processing
1): Steel making process:
EF+LF+VD
EAF+LF+VD
EF+LF+VD+ESR
EAF+LF+VD+ESR
2): Forging processing:
Hot forging temperature: 900-1200℃
Cooling in the air
7: Heat treatment
1）: Solution annealing
Heat 316 steel to 1010-1150℃ in the furnace
Quick cool in the air/water
2): Aging
Heat to 850-930℃
8：Application
316 stainless steel is widely used in a variety of harsh environments due to its excellent corrosion resistance, high temperature strength and processability. The following are its main application areas:
1. Chemical and petroleum industry
(1) Corrosion-resistant equipment: used in reactors, heat exchangers, pipelines, valves, pumps, etc..
(2) Marine environment: used in offshore oil platform equipment, seawater treatment system.
2. Food and pharmaceutical industry
(1) Sanitary equipment: used in food processing equipment (such as fermentation tanks, conveying pipelines), pharmaceutical machinery.
(2) Medical devices: for surgical instruments, implants (such as orthopedic screws).
3. Energy and environmental protection
(1) Nuclear power equipment: for nuclear fuel assembly auxiliary components.
(2) Desulfurization equipment: for flue gas desulfurization (FGD) systems.
4. Construction and Marine Engineering
(1) Coastal construction: for bridges, railings, curtain walls.
(2) Seawater desalination: for reverse osmosis membrane components, high-pressure piping.
5. Daily life and high-end supplies: for kitchenware, tableware, jewelry, watches, etc.
6. Aerospace: for fuel lines, hydraulic system components.
7. Automotive industry: used for exhaust systems, sensors.
