X35CrWMoV5
Qilu
Country | ISO | Germany | Japan | USA |
Standard | ISO 4957 | DIN 17350 | JIS G4404 | AISI/ASTM ASTM A681 |
Grade | X35CrWMoV5/ 1.2605 | X37CrMoWV5-1/ 1.2606 | SKD62 | H12 |
2: Chemical composition
Grade | C | Si | Mn | Cr | Mo | W | P | S | V |
| X35CrWMoV5/ 1.2605 | 0.32-0.40 | 0.80-1.20 | 0.20-0.50 | 4.75-5.50 | 1.25-1.60 | 1.10-1.60 | 0.030 Max | 0.020 Max | 0.20-0.50 |
| SKD62 | 0.32-0.40 | 0.80-1.20 | 0.20-0.50 | 4.75-5.50 | 1.00-1.60 | 1.00-1.60 | 0.030 Max | 0.020 Max | 0.20-0.50 |
| H12 | 0.30-0.40 | 0.80-1.25 | 0.20-0.60 | 4.75-5.50 | 1.25-1.75 | 1.00-1.70 | 0.030 Max | 0.030 Max | 0.20-0.50 |
3: Surface hardness and hardenability
Heat Treatment | Hardness |
Annealed (+A) | HB229Max |
| Hardening and Tempering (+HT) | HRC48 Min |
| Cold-drawn condition | HB262Max |
| Quenched and tempred (+QT) | HRC28-32(Common Range) |
4: Supply size & Tolerance & Stock size
Product type | Size range | Length |
Hot rolled bar | Φ10-Φ190mm | 2000-5800mm |
Hot forged bar | Φ200-Φ600mm | 2000-5800mm |
Hot rolled plate/sheet | T:10-60mm; W:310-810mm | 2000-5800mm |
Hot forged plate | T:70-250mm; W:310-810mm | 2000-5800mm |
Hot Forged block | T: 260-500mm; W: 300-1000mm | 2000-5800mm |
Surface Finish | Turned | Milled | Grinding(Best) | Polished(Best) | Peeled(Best) | Black Forged | Black Rolled |
Tolerance | +0/+3mm | +0/+3mm | +0/+0.05mm | +0/+0.05mm | +0/+0.1mm | +0/+5mm | +0/+1mm |
Straighness | 1mm/1000mm max. | 3mm/1000mm max. | |||||
To ensure optimal performance for your application, we produce 1.2605 tool steel on a dedicated make-to-order basis. This approach guarantees fresh production and allows us to customize the process for your specific requirements. Tell us your needs, and let's get started.
5: Ultrasonic Test
EN10228-3 class III or Sep 1921-84 D/D
6：Steel making & Forging processing
1): Steel making process:
EF+LF+VD
EAF+LF+VD
EF+LF+VD+ESR
EAF+LF+VD+ESR
2): Forging processing:
Initial temperature: 1100-1150℃
Final temperature: 950℃
Cooling in the furnace or in the sand
7: Heat treatment
1): Annealed:
Heat 1.2605 steel to 820-840℃
Cooling in the furnace.
2): Quenching and tempering:
Heat 1.2605 steel to 1010-1030℃ in the salt bath furnace
Quench in the Oil
Temper steel at 540-560℃ in the furnace
Cooling in the air.
Above curve in figure is a rough guide to the tempering behaviour of steels.
8：Application
1.2605 Steel—High heat resistance, excellent thermal shock toughness, good wear resistance, and high-temperature hardness. Its applications are highly specialized, primarily serving hot-working die scenarios with extremely demanding temperature requirements. Below are the main application categories for 1.2605 steel:
1. High-Temperature Metal Die Casting and Extrusion Dies
Copper Alloy and Heavy Metal Alloy Die Casting: Brass and bronze faucets, valves, gears, connectors, etc.
Aluminum Alloy Die Casting: Engine blocks, cylinder heads, transmission housings, wheel hubs, etc.
Hot extrusion dies: For producing bars, tubes, and profiles from copper/copper alloys and aluminum/aluminum alloys
2. Other hot-work tooling applications
Hot stamping and hot forging dies: Punch and die components for forging high-alloy steels, titanium alloys, or other high-melting-point metals
Plastic molds: For processing highly corrosive plastics (e.g., PVC) or engineering plastics requiring high-temperature forming
