1.2210 is a widely recognized cold work tool steel that belongs to the German standard DIN 17350. It is known for its high wear resistance, good toughness, and excellent dimensional stability during heat treatment. Due to its reliable performance and broad applications, many countries have equivalent steel grades to DIN 1.2210, such as L2 from the American standard ASTM A681, 115CrV3 from International standard ISO 4957, and SKS43 from the Japanese standard JIS G4404.
1.2210 steel contains chromium, nickel, and molybdenum, which contribute to its hardness and toughness. The nickel content enhances its impact resistance, while the molybdenum improves hardenability and wear resistance.
| Quantity: | |
|---|---|
AISI L2 Cold Work Tool Steel (DIN 115CrV3 1.2210, JIS SKS43) is a globally recognized cold work tool steel compliant with DIN 17350 and ASTM A681 standards. Engineered for demanding cold-forming and cutting applications, this grade stands out for its exceptional wear resistance, high toughness, and dimensional stability during heat treatment. DIN 115CrV3 1.2210 Steel contains chromium, vanadium, and trace alloys that enhance hardness and durability—making it a top choice for molds, tools, and precision components. With equivalents including ISO 115CrV3 and JIS SKS43, it offers consistent performance across international manufacturing workflows.
The high carbon (1.10-1.25% for DIN 115CrV3) and chromium (0.5-0.8%) content forms hard carbides, delivering superior wear resistance for repetitive cold-working operations.
During heat treatment, JIS SKS43 Tool Steel maintains tight tolerances—critical for precision molds and tools where dimensional accuracy directly impacts product quality.
Unlike brittle high-carbon steels, AISI L2 combines HRC 60+ hardness (after heat treatment) with good toughness—resisting chipping and cracking during high-impact cold forming.
It accommodates various manufacturing processes, including forging, machining, and heat treatment, with consistent performance across different supply forms.
1: Steel equivalent
Country | USA | ISO | Germany | Japan |
Standard | ASTM A681 | ISO 4957 | DIN17350 | JIS G4404 |
Grade | L2 | 115CrV3 | 1.2210 | SKS43 |
2: Chemical composition
Grade | C | Si | Mn | P | S | Cr | Mo | V |
L2 | 0.45-1.00 | 0.10-0.50 | 0.10-0.90 | 0.030Max | 0.030Max | 0.7-1.2 | 0.25Max | 0.10-0.30 |
115CrV3/1.2210 | 1.10-1.25 | 0.15-0.30 | 0.20-0.40 | 0.030Max | 0.030Max | 0.5-0.8 | / | 0.07-0.12 |
SKS43 | 1.00-1.10 | 0.10-0.30 | 0.10-0.40 | 0.030Max | 0.030Max | 0.20Max | / | 0.10-0.20 |
3: Surface hardness and hardenability
Heat Treatment | Hardness |
Annealed (+A) | HB223Max |
Cold-drawn condition | HB241Max |
Hardening and Tempering (+HT) | HRC60 Min |
4: Supply size & Tolerance & Stock size
Product type | Size range | Length |
Hot rolled bar | Φ10-Φ190mm | 2000-5800mm |
Hot forged bar | Φ200-Φ600mm | 2000-5800mm |
Hot rolled plate/sheet | T:10-60mm; W:310-810mm | 2000-5800mm |
Hot forged plate | T:70-250mm; W:310-810mm | 2000-5800mm |
Hot Forged block | T: 260-500mm; W: 300-1000mm | 2000-5800mm |
Surface Finish | Turned | Milled | Grinding(Best) | Polished(Best) | Peeled(Best) | Black Forged | Black Rolled |
Tolerance | +0/+3mm | +0/+3mm | +0/+0.05mm | +0/+0.05mm | +0/+0.1mm | +0/+5mm | +0/+1mm |
Straighness | 1mm/1000mm max. | 3mm/1000mm max. | |||||
5: Ultrasonic Test
EN10228-3 class III or Sep 1921-84 D/D
6：Steel making & Forging processing
1): Steel making process:
EF+LF+VD
EAF+LF+VD
EF+LF+VD+ESR
EAF+LF+VD+ESR
2): Forging processing:
Pre-heat 1.2210 steel in 500-550°C to avoid cracking and reduce thermal stresses.
Initial temperature: 1050-1100℃
Final temperature: 850-900℃
Cooling in the sand
7: Heat treatment
1): Annealed:
Heat 1.2210 steel to 760-780℃
Furnace cooling (≤20°C/hour) to approx. 600°C, then air cooling.
2): Quenching and tempering:
Preheat Temperature: 649℃
Heat 1.2210 steel to 870-890℃ in the salt bath furnace
Quench in oil
Temper steel at 204℃ in the furnace
Cooling in the air
Above curve in figure is a rough guide to the tempering behaviour of steels.
Stamping molds: High-precision punching, trimming, and blanking molds (ideal for stainless steel and high-strength steel plates)
Stretching molds: Deep drawing molds for automobile covers, home appliance shells (dimensional stability)
Cold heading molds: For bolts, nuts, and rivets (resists high impact loads)
Extrusion molds: Cold extrusion of aluminum, copper, and non-ferrous metals (wear resistance)
Scissor blades: Industrial shear blades for metal sheets and wires (sharp edge retention)
Punch & concave molds: Precision blanking for electronic connectors and hardware (tight tolerances)
Injection mold cores: For glass fiber-filled or mineral-filled engineering plastics (high wear resistance)
Die-casting mold inserts: For zinc and aluminum alloys (thermal fatigue resistance)
Gauges & fixtures: High-precision measuring blocks and positioning pins (dimensional stability)
Bearings & guide rails: Wear-resistant components for high-load, low-speed applications
Anneal at 760-780℃ (furnace cool ≤20℃/hour to 600℃, then air cool); quench at 870-890℃ (salt bath furnace, oil quench); temper at 204℃ (air cool) for HRC 60+ hardness.
No—AISI L2 is designed for cold work (room temperature to 200℃). For hot work, choose dedicated hot work tool steels like H13.
Due to limited domestic demand, there is no regular stock. Custom orders are available with flexible supply forms and sizes.
It meets EN10228-3 Class III or Sep 1921-84 D/D standards—ensuring internal quality and minimizing defects.
